| Quantity: | |
|---|---|
DIDTEK
Globe
Didtek provide cast steel, stainless steel, special alloy, CI, DI etc
Didtek Produce Globe Valve
100% quantity tested before delivery
18 months after shipments and 12 months after installed
| Brand | DIDTEK |
| Valve Structure | Globe Valve |
| Valve Delivery | 15 - 30 days |
| Valve Sample | Sample Available by Didtek Valve |
| Valve Color | Customer request |
| Valve Packing | Plywood Case for Gate Valve |
| MOQ | 1 Set |
| Valve Certificate | API6D/CE/ISO9001/ISO14001 |
| Place of Origin | Zhejiang, China (Mainland) |
| Delivery Detail: | Shipped in 15-30 days after payment |
| Port | Shanghai Or Ningbo |
| Payment Terms | L/C,D/A,D/P,T/T, Western Union |
Applicable Standards: Globe valve, BS1873 Steel valve, ASME B16.34 Face to face ASME B16.10 End Flanges ASME B16.5/ASME B16.47 Butt welding ends ASME B16.25 Inspection and test API 598 Material: CF8M Operated: Hand wheel Size Range: 2"~36" Pressure Rating: ASME CL, 150,300,600,900,1500,2500 Temperature Range: -196°C~600°C |
|
Design Description: - Outside Screw and Yoke - Bolted Bonnet and Pressure Seal - Flexible and solid wedge, fully guide - Welding seat rings or Renewable seat rings - Rising stem and non-rising stem - Available with gear operator - Flange Ends & Buttwelding Ends - Low torque design, smooth surface stem |
|
Globe Valve -API600 -Materials:
Parts Name | Part Name | Carbon Steel to ASTM | Alloy Steel to ASTM | Stainless Steel to ASTM | |||||||
1 | Body | A216WCB | A352 LCB | A217 WC1 | A217 WC6 | A217 WC9 | A217C5 | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M |
2 | Seat | A105+13Cr | F11/F22+STL | 304 | 316 | 304L | 316L | ||||
3 | Disc | A216 WCB+13Cr | A352 LCB+304 | A217 WC1+STL | A217 WC6+STL | A217 WC9+STL | A217 C5+STL | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M |
4 | Hinge | A216 WCB | A352 LCB | A217 WC1 | A217 WC6 | A217 WC9 | A217 C5 | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M |
5 | Disc Washer | AISI 1035 | Stainless Steel | ||||||||
Globe Valve -API600 -Table Of Available Dimensions:
Application & Function:
Didtek Cast steel globe valve is used for throttling flow control. Shut off is accomplished by moving the disc against the flow stream rather than across it as in the case with a gate valve. The flow pattern through a globe valve involves changes in direction, resulting in greater resistance to flow, causing high pressure drop. Didtek Cast steel Globe valve is an excellent valve to use for on-off service, also is highly suited for frequent cycling and control of fluids anywhere in amount or volume between the open and closed positions.
Didtek Cast steel globe valve must be installed in the proper relation to the media flow as indicated by the flow direction arrow marked on the valve body. This valve is considered uni-directional and must be installed with the pressure side or inlet under the seat.
Accessories:
Accessories such as gear operators, actuators, bypasses,locking devices, chain wheels, extended stems and bonnets for cryogenic service and many others are available to meet the customers' requirements.
